Ø Small size, easy to integrate into terminal devices
Ø Support 82.5mm paper width
Ø Support real-time control of printing quality
Ø Support automatic paper feeding mode
Ø Power Voltage：24V±10%
Ø Support USB/RS232
Ø Support GDI prinitng mode
Ø Support black mark position，ensure the consistency of bill length
Ø Support paper near end detection for early warning of paper surplus
Ø Support paper output detection function, achieve ticket clamping mode and bullet mode
Item | Parameters |
Print method | Thermal Printing |
Print width | 80mm |
Paper width | MAX82.5mm |
Paper thickness | 60~250g/m² |
Roll diameter | Outer diameter：Max150mm inner diameter：Min25.4mm |
Resolution | 203dpi |
Dot density | 8dots/mm |
Paper feed method | 180°automatic feeding |
Print speed | MAX150mm/s |
Paper output | ticket clamping mode and bullet mode |
Support character | ●FONT A:12×24（1.5×3mm）dot character ●FONT B:9×17（1.125×2.125mm）dot character ●chinese character：support GB18030 simple chinese（compatible GB2312-1980） Note：GB18030 support double character 1、2、3、4、5 region |
Barcode | ●1D：EAN8、EAN13、CODE93、CODE128 ●2D：QR、PDF417 |
Interface | RS232/USB |
Receive buffer | 2MB |
Command | ESC/POS |
OS | windows XP/WIN 7/8/Linux/Andorid |
detection | No paper、pear near end、open up detection、motor temperature、black mark、paper out、cut paper jam |
Cutter | Auto cutter full cutting |
Power | 24VDC±10%，2.5A full format all black printing 6A |
Energy consumption | 150W |
Environmental conditions | temperature：0~50℃ humidity：20~85%RH |
Storage | Temperature：-25~70℃ humidity：0~90%RH(not include papers) |
Reliability | Print head lifetime：100KM Cutter lifetime：1000000 cuts |
Airport、Medical Care、Public safety、Transportation、Social insurance, Energy, Gas stations, Hydropower, Government, Education.
